Maximum rated power: 42.7 BHP
Stroke length: 2.5 in (63.5 mm)
Frame load rating: 6,438 lbs
Fluid cylinder pressure rating: 2,251 PSI
Pump weight (avg.): ~1,000 lbs (455 kg)
Kerr max speed: (not specified; typically up to 400–600 RPM)
Minimum speed: 100 RPM
Mechanical efficiency (bare shaft): 90%
Lubrication system: Splash – gravity feed (standard), force feed (optional)
Lube oil capacity: 12 quarts (11.36 liters)
Lube oil type: Petroleum per AGMA 5EP (ISO 220) or Synthetic per SAE 75W-90 (ISO 100)
Connection sizes: 2.5" NPT suction, 1.25" NPT discharge
Maximum rated power: 47 BHP
Stroke length: 2.5 in (63.5 mm)
Frame load rating: 6,438 lbs
Specifications
High flow, L / min
121
High pressure, bar
155
Dimensions and weight
