Model:

FMC-435

Brand:

FMC

No. of plungers: 2

Maximum rated speed: 500 rpm

Stroke length: 1.0 in (25.4 mm)

Maximum rated power: 2.7 HP

Maximum rod load: 1200 lbs (544 kg)

Weight: 43 lbs (19.5 kg)

Maximum pressure: 850 psi (58.6 bar)

Maximum flow rate: 5.3 GPM (20.1 L/min) at 500 rpm

High flow, L / min

201

High pressure, bar

Questions: 0

No questions about this product.
