Model:
FMC-L0618Brand:
FMCNo. of plungers: 3
Maximum rated speed: 500 RPM (intermittent), 350 RPM (continuous)
Stroke length: 1.5 in (38.1 mm)
Maximum rated power: 17.6 HP (intermittent), 12.3 HP (continuous)
Maximum rod load: 2,800 lbs (1,270 kg)
Weight: 175 lbs (79.4 kg)
Specifications
High flow, L / min
176
High pressure, bar
108
Dimensions and weight
