No. of plungers: 3
Maximum rated speed: 750 RPM (continuous), 890 RPM (intermittent)
Stroke length: 2.25 in (57.15 mm)
Maximum rated power: 11.6 BHP (continuous), 13.8 BHP (intermittent)
Maximum rod load: 2,800 lbs (1,270 kg)
Weight: 200 lbs (91 kg)
Specifications
High flow, L / min
264
High pressure, bar
103
Dimensions and weight
