Designed for demanding oilfield conditions, this valve controls fluid intake, opening during the piston's backstroke to allow mud flow.
This valve is compatible with APLEX MA-25L,MA-75M,SC-45L mud pumps.
Key advantages:
- Precision fit for minimal flow restriction
- Wear-resistant materials for extended use
- Simple design allows quick replacement
- Reliable sealing under vacuum conditions
Suction valve assembly for APLEX MA-25L,MA-75M,SC-45L (BG-TS18-AR0-AC0714)
Brand pump
Brand pump
APLEX
Dimensions and weight
Questions: 0
No questions about this product.
