Maximum rated power: 2,350 HP
Maximum pressure: 7,500 PSI (517 bar) (with optional high-pressure fluid end)
Maximum flow rate: up to 1,200 GPM (4,540 L/min) (depends on liner/piston diameter and stroke)
Stroke length: 12 in (304.8 mm)
Piston/liner diameter: 7"–5" (178–127 mm) (selected based on required pressure and flow)
Maximum speed: up to 120 SPM (strokes per minute)
Crankcase oil capacity: 85 liters (22 gallons)
Weight: 3,855 kg (8,500 lbs) (pump only)
Specifications
High flow, L / min
4540
High pressure, bar
517
Dimensions and weight
